Technic Axle Pin Connector #4 Ring

image of the building technique
  • ID: #134
  • Added: Nov. 19, 2016
  • Last Update: Aug. 23, 2026 [da473dc]
  • LDraw File: Download
  • Size: 10s × 10s × 1s
  • Parts: 16 [2 per segment]
Technic Axle and Pin Connector Angled #4 - 135°
Technic Axle 2
Images from Rebrickable API
Axle Tilt: 45° Axle Tilt: 90° Polygon: 8 Sides
#4 Connector 45 Pythagorasfds
AlienShadowMaster (2015-09-16, flickr.com)

I also played around with the Pythagoras theorem and found the two practical values to use: 5 ( 6L in LEGO the first L is the 0 position ) and 7.071 { 5.sqrt(2) } rounded to 7 ( 8L in LEGO the first L is the 0 position ) 7 ( 8L in LEGO the first L is the 0 position ) and 9.899 { 7.sqrt(2) } rounded to 10 ( 11L in LEGO the first L is the 0 position )
